Effluent pump
150SLA
Sealless design to let pump work very long time
Built-in reliability ease of operation
Wide-angle float switch available for wide pumping application
Model | JSW-150SLA |
Typical Application | Sump / Effluent pump |
Capacities | up to 30 GPM |
Heads | up to 22 FT |
Motor | 1/3 HP PSC motor |
Operation | Wide-Angel float |
Materials of Construction | Aluminum housing thermoplastic volute |
Discharge Size | 1-1/2” NPT |
JSW100
Removes water down to 1/8”depth ‧Provides longer life than similar size pumps
Light weight design‧Efficient PSC motor
Built-in carrying handle‧Air-filled motor housing , no oil required
Built-in thermal overload protector
Model | JSW-100 |
Typical Application | Light-duty drainage,flooded basements , flat roofs , swimming pool |
Capacities | up to 22 GPM |
Heads | up to 22 FT |
Liquids | Drain water |
Intermittent Liquid Temp | up to 60℃ |
Electrical | 115V , 60Hz or 240V , 50Hz |
Motor | 1/6HP PSC |
Operation | Manual , wide Angel Float |
Materials of Construction | Thermoplastic |
Discharge Size | 1” NPT |
Solids Handling | 1/8 “ |
Power Cord | 10’, SJTW or SJTW-A |
JSW100R
Removes water down to 1/8”depth ‧Provides longer life than similar size pumps
Light weight design‧Efficient PSC motor
Built-in carrying handle‧Air-filled motor housing , no oil required
Built-in thermal overload protector
Model
JSW-100R
Typical Application
Light-duty drainage , flooded basements , flat roofs , swimming pool
Capacities
up to 22 GPM
Heads
up to 22 FT
Liquids
Drain water
Intermittent Liquid Temp
up to 60℃
Electrical
115V , 60Hz or 240V , 50Hz
Motor
1/6HP PSC
Operation
Manual , wide Angel Float
Materials of Construction
Thermoplastic
Discharge Size
1” NPT
Solids Handling
1/8 “
Power Cord
10’, SJTW or SJTW-A
200IE
Carbon ceramicinboard design with secondary rotary V-seal for lone life operation
High flow design
With oil-filled motor for good cooling
Model
JSW-200IE
Typical Application
Sump / Effluent
Capacities
up to 45 GPM
Heads
up to 50 FT
Motor
1/2HP PSC motor
Operation
Manual , wide Angel Float
Solids Handling
3/4 “
Housing
all cast iron
Impeller
cast iron vortex
Seal
inboard design with secondary rotary
Discharge Size
1” NPT
150IA
In board design with secondary rotary V-seal Wide angel vertical floating available
Oil-filled motor for very good cooling
Non-clog vortex impeller design for heavy wasting water pumping purpose
Model
JSW-150IA
Typical Application
High-capacity sump , effluent
Capacities
up to 85 GPM
Heads
up to 20 FT
Motor
1/2 HP , PSC Motor
Solids Handling
1“
Discharge Size
1-1/2” NPT
Housing & Volute
All cast-iron design
200BW
Carbon Ceramic Inboard Design with Secondary Rotary V-seal
Oil-filled motor with built-in thermal protecter
Model
JSW-200BW
Typical Application
High capacity sewage
HP
1/2
Volt
115 or 230
Phase
1
Motor
PSC Oil Filled
Capacity-flows
To 109GPM
Capacity-heads
To 26’ THD
Solids Handing
2”
Housing
Cast Iron
Impeller
Cast Iron Vortex
Bearing
Upper & Lower Ball
Seal
Carbon Ceramic Inboard Design with Secondary
Rotary V-SealFloat
Manual ; Wide Angle Float ; Vertical
Cord Length
10’ Standard , 20’ & 30’ Optional
Discharge Size
2”
